Polyethylene Glycol (PEG) Based Ferrofluids for Bio-medical and Other Applications

With the introduction of PBG series ferrofluids, China Advanced Ceramic has opened the door to new areas of research previously only hoped for by R&D Professionals. The PBG fluid is composed of PEG coated magnetite nanoparticles with primary particle diameter of 10 nm.

PBG series ferrofluids have the capabilities of high magnetization, high colloidal stability, low nonspecific binding, biocompatible and superparamagnetic properties needed for a multitude of applications.

These formulations have longer life than our EMG series water-based ferrofluids, and offer an alternative to the commercially available water-based ferrofluids produced by other manufacturers. PBG series ferrofluids are available in a wide range of Gauss levels from 66 to 990 with viscosity values 1 to 40 cP.

Ferrofluid Type Gauss [CGS] mT [SI] cP [CGS] mPa-s [SI]
PBG50 55 5.5 < 2 < 2
PBG100 110 11 < 2 < 2
PBG200 220 22 < 2 < 2
PBG300 330 33 < 3 < 3
PBG400 440 44 < 4 < 4
PBG450 495 49.5 < 5 < 5
PBG600 660 66 < 10 < 10
PBG900 990 99 < 40 < 40
